FATFOOD/10 SD

FATFOOD/10 SD

Milk & fatty foods suction & delivery hose.

TUBE:

White NBR rubber, food quality odourless and taste-free .

REINFORCEMENT:

High tensile synthetic cord with steel helix body wire.

COVER:

Blue NBR rubber, ozone, abrasion and weathering resistant.

KEY FEATURES:

• Hardwall suction and delivery structure.
• Compact, lightweight and flexible.
• Robust hose structure for longer life in severe applications.
• Long length assemblies available – Max length: 61m.

APPLICATION & FLUIDS:

Suction and delivery of milk and fatty foods.

TEMPERATURE RANGE:

From -40°C to + 80°C (-40°F to +176°F) – sterilization at 110°C / 230°F for 30 minutes.

WORKING PRESSURE:

Maximum working pressures are based on 3:1 safety factor (maximum working pressure to minimum burst pressure).

APPLICABLE SPECS:

FDA title 21 art. 177.2600 (f ) for fatty foods; BfR; ADI free;

D.M. 21/03/73; CE 1935/2004; PHTHALATE free.

COUPLINGS:

TWO-PIECE CRIMP

SR + D08000 Series.
