C6000S SLIDER

C6000S RYCO SLIDER

Ultra flexible extremely abrasion resistant isobaric spiral hose 420 BAR / 6100 PSI million cycle.

RECOMMENDED FOR:

Ultra flexiblility and small bend radius provides easy installation in compact environments.

Extremely high pressure hydraulic oil lines.

Constant pressure (Isobaric) 420 bar / 6100 psi in all sizes.

PERFORMANCE:

Meets or Exceeds the Performance Requirements of:

ISO 18752-CC, SAE 100R15.

TUBE:

Black, oil resistant synthetic rubber.

REINFORCEMENT:

Four alternating layers of spiralled high tensile steel wire.

COVER:

SLIDER Black, oil and extremely abrasion resistant synthetic rubber sheathed with a layer of extremely abrasion resistant polyethylene. Flame Resistant, MSHA compliant.

Highly visible layline branding for easy and permanent identification. No skiving required with T7000 Series Crimp Couplings.

FEATURES:

Ultra flexibility combined with a small bend radius reduces effort during assembly and installations. Tested to 1 million impulse cycles at up to 1/2 SAE 100R15 Minimum Bend Radius.

Constant pressure 420 bar / 6100 psi in all sizes for easy system design and hose selection.

MSHA – FLAME RESISTANCE:

SLIDER complies with Flame Resistant requirements of Australian Standard AS 2660 and Methods of Test AS 1180.10B. Meets Flame Resistant Designation “U.S. MSHA” of the US Department of Labor, Mine Safety and Health Administration.

TEMPERATURE RANGE:

-40°C to +121°C (-40°F to +250°F).

WORKING PRESSURE:

Maximum working pressures are based on 4:1 safety factor (maximum working pressure to minimum burst pressure).

COUPLINGS:

NON-SKIVE ONE-PIECE CRIMP

T7000 Series (sizes -12 to -16).

C6000S – DIEHARD
