| BULK MATERIAL/10 D | MATCH COUPLING SERIES | ||
| PART NO | HOSE SIZE | TWO-PIECE | |
| HOSE | DN | INCH | NON-SKIVE |
| BM10D32 | 51 | 2″ | SR+D08000 SERIES |
| BM10D48 | 76 | 3″ | SR+D08000 SERIES |
Additional information
BULK MATERIAL/10 D
BULK MATERIAL/10 D
Abrasive fluid hose heavy duty.
TUBE:
Black, NR/SBR rubber, abrasion resistant thick tube.
REINFORCEMENT:
High tensile synthetic cord with 2 crossing copper wires for grounding.
COVER:
Black, NR/SBR rubber, abrasion resistant.
KEY FEATURES:
- Softwall delivery structure.
- High resistance to continuous abrasion.
- Long length assemblies available – Max length: 60m.
APPLICATION & FLUIDS:
Dry and liquid abrasive mix transfer.
TEMPERATURE RANGE:
From -40°C to + 80°C (-40°F to +176°F).
WORKING PRESSURE:
Maximum working pressures are based on 3:1 safety factor (maximum working pressure to minimum burst pressure).
COUPLINGS:
TWO-PIECE CRIMP
SR + D08000 Series.
